Product Description:

The Drive Gear Motor is a high-quality AC gear motor that is specially designed for industrial equipment. With its powerful engine gear and advanced control system, it offers efficient and reliable performance, making it the perfect choice for various industrial applications.

• Type: AC Gear Motor
• Protection Class: IP55
• Operating Temperature: -20°C to 40°C
• Rated Current: 18,20 / 10,50
• Rated Voltage: 230/400

The Drive Gear Motor is an AC motor that is known for its high performance and versatility. It is suitable for a wide range of industrial applications, from conveyors to pumps, and offers efficient and reliable power for your equipment.

The Drive Gear Motor is equipped with an advanced control system that allows for precise speed and power control. This enables you to adjust the motor's performance to meet the specific requirements of your industrial equipment, ensuring optimal efficiency and productivity.

The Drive Gear Motor is designed to withstand even the most demanding industrial environments. With its IP55 protection class and operating temperature range of -20°C to 40°C, it can operate in harsh conditions and deliver consistent performance, making it a reliable choice for your industrial equipment.

The Drive Gear Motor is designed for easy installation and maintenance. With its compact and lightweight design, it can be easily integrated into your equipment. Additionally, it requires minimal maintenance, saving you time and effort in the long run.

In conclusion, the Drive Gear Motor is the ultimate solution for your industrial equipment needs. With its efficient and versatile AC motor, advanced control system, and durability, it offers superior performance and reliability. Choose the Drive Gear Motor and take your industrial equipment to the next level.

Features:

• Product Name: Drive Gear Motor
• Rated Power: 5.5
• Protection Class: IP55
• Gear Ratio: 174.4
• Rated Current: 18,20 / 10,50
• Weight: 321kg
• Engine Gear
• Gear Shafts
• AC Motor
• High Torque

Technical Parameters:

Catalog designation: R137 DRN132S4/BE11HR/TH/ES7C/V
Product: Helical gearmotors R..DRN.. (IE3)
Speed 50Hz [r/min]: 1464 / 8.4
Total ratio [i]: 174.40
Ma max [Nm]: 8000
Output torque 50Hz [Nm]: 6260
Service factor SEW-FB: 1.30
Mounting position: M1
ISO code: CLP 220
Lubricant type: Miner.Oil
Lubricant volume [l]: 10.00
Motor power [kW]: 5.5
Motor frequency [Hz]: 50
Cyclic duration factor S1-S10: S1
Voltage range [V]: 220-230 delta/380-400 star
Nominal current [A]: 18.20 / 10.50
cos phi: 0.84

Applications:

Are you looking for a reliable and durable drive gear motor for your industrial automation or machinery needs? Look no further, because we have the perfect solution for you - the R series helical gearmotors hard surface reducer.

• Brand Name: R series helical gearmotors hard surface reducer
• Model Number: R137 DRN132S4BE11HRTHES7CV
• Place of Origin: CHINA
• Certification: CE/3C
• Minimum Order Quantity: 1
• Price: DISSCUS
• Packaging Details: Standard wooden packing
• Delivery Time: 3-5 work days
• Payment Terms: T/T, Western Union
• Supply Ability: T/T, Western Union
• Type: AC Gear Motor
• Rated Current: 18,20 / 10,50
• Rated Torque: 6260
• Gear Ratio: 174.4
• Operating Temperature: -20°C To 40°C

The R series helical gearmotors hard surface reducer is specifically designed for industrial applications that require heavy duty and high-efficiency power transmission. This advanced AC gear motor is perfect for use in machinery such as conveyor belts, factory automation systems, and other industrial processes that require speed control and precise power transmission.

Imagine a factory that produces large volumes of goods using heavy machinery and conveyor belts. These machines require a reliable and durable power source for efficient operation. This is where the R series gear motor comes in, providing a stable and consistent power supply with its advanced technology.

In this scenario, the R series gear motor plays a crucial role in ensuring the smooth functioning of the industrial processes. With its high efficiency and durability, it can withstand heavy loads and continuous operation, making it the perfect choice for heavy-duty industrial applications.

There are many reasons why the R series gear motor stands out from other similar products in the market. Let's take a look at some of its key features:

• Durable and Reliable: The R series gear motor is built with high-quality materials and advanced technology, making it extremely durable and reliable for heavy-duty industrial use.
• High Efficiency: With its advanced gear ratio and powerful motor, the R series gear motor provides high efficiency and precise power transmission.
• Stable Operation: The R series gear motor is designed to provide stable and consistent power supply, ensuring the smooth operation of industrial processes.
• Advanced Technology: This gear motor is equipped with advanced technology that makes it efficient, durable, and reliable, making it the perfect solution for industrial automation and machinery needs.

So why wait? Choose the R series helical gearmotors hard surface reducer for your industrial automation and machinery needs and experience the ultimate solution for efficient power transmission. Contact us now for more information and to place your order!

FAQ:

• Q: What is the brand name of this product?
  A: The brand name of this product is R series helical gearmotors hard surface reducer.
• Q: What is the model number of this product?
  A: The model number of this product is R137 DRN132S4BE11HRTHES7CV.
• Q: Where is this product manufactured?
  A: This product is manufactured in China.
• Q: Is this product certified?
  A: Yes, this product is certified with CE/3C.
• Q: What is the minimum order quantity for this product?
  A: The minimum order quantity for this product is 1.
