    ODM Hollow Shaft 2 Hp Worm Gear Motor 31.43 M4A 1010NM

    Ask Lasest Price
    Brand Name : SEW
    Model Number : SA87 DRN132S4
    Certification : CE/3C
    Price : Discussed
    Payment Terms : T/T, Western Union
    Supply Ability : 1000000 pieces/year
    Delivery Time : 5-7works day
    • Product Details
    • Company Profile

    ODM Hollow Shaft 2 Hp Worm Gear Motor 31.43 M4A 1010NM

    ▶▶▶Description
    Helical-worm gearmotors
    Low-noise continuous operation: gear unit combination optimized with respect to efficiency


    Due to their design and from being combined with a helical gear stage, the helical-worm gearmotors S..DR.. have particularly high efficiency. They are also extremely low-noise and thus avoid high noise emission levels.


    S series Helical-worm gearmotors
    ✪●✪
    P
    roduct size&Technical data
    Gear unit sizeS37S47S57S67
    Motor Power(KW)0.12-30.12-30.12-7.50.12-7.5
    gear ratio range3.98-106.384.64-131.874.69-145.145.2-144.79
    Mamax Gear unit(Nm)200400600820



    ▶▶▶Features

    Helical-worm gear units
    •Helical-worm combinations with significantly better efficiency than single helical-worm gear units
    •Very low-noise operation
    •Available variants:
    •Foot- or flange-mounted
    •B5 or B14 flange-mounted
    •Solid or hollow shaft
    •Hollow shaft with keyed connection, shrink disk, splined hollow shaft, or TorqLOC®


    ▶▶▶Production details

    Catalog designationSA87 DRN132S4
    ProductHelical-worm gearmotors S..DRN.. (IE3)
    Product data
    Speed 50Hz [r/min]1464 / 47
    Total ratio [i]31,43
    Ma max [Nm]1.600
    Output torque 50Hz [Nm]1010
    Service factor SEW-FB1,60
    Mounting positionM2A
    ISO codeCLP 680
    Lubricant typeMiner.Oil
    Lubricant volume [l]7,40
    Motor power [kW]5.5
    Motor frequency [Hz]50
    Cyclic duration factor S1-S10S1
    Voltage range [V]220-230 delta/380-400 star
    Nominal current [A]18,20 / 10,50
    cos phi0,84
    Thermal cl.[°C]/Enclosure[IP]155(F) / 55
    International efficiency classIE3
    Efficiency (100% Pn) [%]89,6


    ▶▶▶Areas of application
    ◆Drives in theater applications ◆Adjustment drives ◆Presses
    ◆Rotary tables ◆Corner transfer units



    ▶▶▶ SEW S series Helical-worm gearmotors

    out speed (rpm): 0.1rpm - 397 rpm
    Torque range(Nm)/Power range(KW): 200Nm - 4,200 Nm/0.12KW - 37 kW
    SIZE:S37,S47,S57,S67,S77,S87,S97
    SF37,SF47,SF57,SF67,SF77,SF87,SF9
    SAF37,SAF47,SAF57,SAF67,SAF77,SAF87,SAF97
    SAT37,SAT47,SAT57,SAT67,SAT77,SAT87,SAT97


    ▶▶▶FAQ

    Q: What documents are available?
    A:A full range documents including structural drawings, packing list, installation manual and relative certificates can be provided. Moreover, customs declaration is provided. We provide one-stop service for you.


    Q:How to choose a gearbox which meets your requirement?
    A:You can refer to our catalogue to choose the gearbox or we can help to choose when you provide
    the technical information of required output torque, output speed and motor parameter etc.
